GRAN GIOIA MK2 (ti)(be)

GRAN GIOIA MK2

BASS PHASE

We aimed to deliver the full-horn Blumenhofer experience in a compact yet elegant solution such as the smaller brother Gran Gioia 2x10. While the Gran Gioia MK2 shares much of the technologies, the Gran Gioia MK2 builds it up by only adopting a single 16” paper woofer; this, in turn, allows the speaker to reach even more performance by being naturally more sensitive and allowing even the most cherished valve power amplifiers to output concert-levels of sound output thanks to its 100 dB sensitivity. The result is an outstanding communicating loudspeaker, able to portray the smallest minute shades and colours in music with total authority when required.

HARMONIC

CONSTRUCTION

Despite being a two-way design, the Gran Gioia MK2 renders music with outstanding authority and control as if it were a much bigger and more complex design. The harmonic construction allows the Gran Gioia MK2 to offer massive soundscapes and transparency thanks to its simplistic two-way design, but it doesn’t end there.

For those requiring even more performance from the Titanium driver, an upgraded Beryllium alternative is offered to enhance performance further against any cost-no-object alternative.

GRAN GIOIA MK2 (ti) (be) TECHNICAL SPECIFICATIONS

MATERIAL:

Birch plywood

HORN MATERIAL:

HDF-Complex

THICKNESS:

19mm / 0,75"

Internal Bracing:

Structural bracing interaction

CROSSOVER CHAMBER:

Yes

Frequency range:

35Hz - 20kHz ± 2dB

BASS CABINET:

Horn bass reflex

PORTING:

Floor

woofer DRIVER specifications

WOOFER:

380mm / 15"

material:

Paper

CROSSOVER FREQ:

850 Hz

HORN LOAD:

Front

MID-HIGH DRIVER specifications

MID-HIGH:

Compression driver

Horn Throat:

1,4"

MEMBRANE DIMENSIONS:

75mm / 3”

material:

Titanium / (Beryllium Optional)

GENERAL specifications

MAX POWER INPUT:

150 W RMS

EFFICIENCY:

100dB

impedance:

8 Ohm

Impedance linearization:

Yes

TERMINALS:

Bi-Wiring

TERMINALS material:

Gold plated tellurium copper

FEET:

Adjustable Spykes

DIMENSIONS :

133.5 x 55 x 84 cm

WEIGHT:

100 kg

Packaging weight:

2x 140 Kg

Warranty parts and labour:

10 years speakers, non trans.

VENEERS specifications

Standard Veneers:

Cherry, Walnut

Special Veneers:

Dark Walnut, Black Walnut, Oak, Maple

Premium Veneers:

Indian Apple, Olive, Elm, Maple Core, Smoked Cherry

HANDMADE

IN GERMANY

The result of all our products is the result of more than 30 years of experience in designing and developing some of the best HiFi speakers in the world.
